Request Datasheet
Linear Actuator
SLA07 Linear Actuator
Heavy-duty 12V/24V DC linear actuator rated up to 8000N, 60W motor, up to 36 mm/s, built-in limit switches, IP54, stroke 50–800 mm.
Key specifications
- Maximum load
- 8000 N
- Stroke
- 50 – 800 mm (customizable)
- Speed
- Up to 36 mm/s
- Voltage
- DC 12 V or DC 24 V
- IP rating
- IP54
- Duty cycle
- 10%
Product overview
Heavy-duty 12V/24V DC linear actuator rated up to 8000N, 60W motor, up to 36 mm/s, built-in limit switches, IP54, stroke 50–800 mm.
- Maximum load
- 8000 N
- Stroke
- 50 – 800 mm (customizable)
- Speed
- Up to 36 mm/s
- Voltage
- DC 12 V or DC 24 V
- IP rating
- IP54
- Duty cycle
- 10%
Applications
- Construction
- Lifting
Benefits
- Up to 8000N load capacity
- 12V or 24V DC input
- 60W motor, speeds up to 36 mm/s
- Built-in limit switches
- T-type lead screw
- Stroke 50 – 800 mm, customizable
- Mechanical life over 30,000 cycles
- CE certified
Technical specifications
| Maximum load | 8000 N |
|---|---|
| Stroke | 50 – 800 mm (customizable) |
| Speed | Up to 36 mm/s |
| Speed options | Up to 36 mm/s |
| Voltage | DC 12 V or DC 24 V |
| IP rating | IP54 |
| Duty cycle | 10% |
| Limit switch | Yes |
| Current | 12V: 5 A max; 24V: 2.5 A max |
| Motor type | 60W DC |
Show 3 more specifications Show fewer specifications
| Operating temperature | -20°C to +65°C |
|---|---|
| Service life | More than 30,000 cycles |
| Certifications | CE |
Request technical documents
FAQ
What is the SLA07?
The SLA07 is an Elerover linear actuator rated IP54.
Does Elerover manufacture the SLA07?
Yes. Elerover is a linear actuator manufacturer and supplier. Share your application requirements and quantity for a factory quote on this model.
What are the key specifications of the SLA07?
Key ratings from the product specifications include voltage 12V / 24V DC, load 8000 N, stroke 50 – 800 mm (customizable), protection IP54. See the Technical Specifications section on this page for the full table.
How do I request a quote for the SLA07?
Send load, stroke, voltage, IP rating, duty cycle and quantity via the contact form or WhatsApp.
Request a quote
Quote context
