SLA45M Linear Actuator
230V AC SLA45M 1500N IP66/IP67M waterproof tubular linear actuator for dynamic facades and sun shading systems from Elerover (datasheet model SLA-T45).
Key specifications
- Maximum load
- 1500 N / 150 kg / 337 lbs (push / pull)
- Stroke
- Up to 300 mm
- Speed
- 9 mm/s (no load)
- Voltage
- 230 V AC
- IP rating
- IP66 / IP67M
- Duty cycle
- 10% (S2): 2 min continuous running, then 18 min rest
Product overview
230V AC SLA45M 1500N IP66/IP67M waterproof tubular linear actuator for dynamic facades and sun shading systems from Elerover (datasheet model SLA-T45). Up to 1500 N at 230V AC, stroke up to 300 mm, installation length from 410 mm + stroke, 10% duty cycle and ≥10,000 cycles service life.
- Maximum load
- 1500 N / 150 kg / 337 lbs (push / pull)
- Stroke
- Up to 300 mm
- Speed
- 9 mm/s (no load)
- Voltage
- 230 V AC
- IP rating
- IP66 / IP67M
- Duty cycle
- 10% (S2): 2 min continuous running, then 18 min rest
Applications
- Dynamic facades
- Sun shading systems
- Window adjustment
- Ventilation systems
Benefits
- Ø45 mm in-line tubular waterproof linear actuator
- Max dynamic force up to 1500 N / 150 kg / 337 lbs, self-locking up to 1500 N
- Voltage: 230V AC, 160 W max power
- Protection: IP66 / IP67M
- Stroke up to 300 mm; installation length from 410 mm + stroke
- 6063 aluminium (stainless steel optional) tube, 316 stainless steel piston rod
- Noise on load ≤60 dB
- Built-in limit switches
Technical specifications
| Maximum load | 1500 N / 150 kg / 337 lbs (push / pull) |
|---|---|
| Stroke | Up to 300 mm |
| Speed | 9 mm/s (no load) |
| Voltage | 230 V AC |
| IP rating | IP66 / IP67M |
| Duty cycle | 10% (S2): 2 min continuous running, then 18 min rest |
| Retracted length | 410 mm + stroke (standard, A = 338.5 mm); 430 mm + stroke with IP67M (A = 338.5 mm) |
| Limit switch | Built-in at both ends |
| Mounting type | Ø10 mm clevis holes at both ends |
| Current | No-load ≤0.7 A; full load ≤0.7 A (230V AC) |
Show 7 more specifications Show fewer specifications
| Noise level | ≤60 dB |
|---|---|
| Housing material | 6063 aluminium (stainless steel optional) |
| Rod material | 316 stainless steel |
| Operating temperature | −20 °C to +85 °C |
| Service life | ≥10,000 cycles |
| Cable length | 1.5 m 4-core cable (custom length available) |
| Certifications | CE |
Dimensions & installation drawing
Retracted length: 410 mm + stroke (standard, A = 338.5 mm); 430 mm + stroke with IP67M (A = 338.5 mm). Extended length = retracted length + stroke (L + 2S).
Performance matrix
| No-load speed | Full-load speed | Thrust | Self-locking force |
|---|---|---|---|
| 4.5 mm/s | 3.5 mm/s | 1500 N | 1500 N |
| 9 mm/s | 6 mm/s | 800 N | 800 N |
| 9 mm/s | 6.5 mm/s | 650 N | 650 N |
| 9 mm/s | 7 mm/s | 400 N | 400 N |
Installation, electrical and use information
Minimum installation length by option · Stroke and weight · SLA45M Wiring, Hall Sensor & Limit Switch Options · Duty Cycle & Service Life
Minimum installation length by option
- Standard (IP66): 410 mm + stroke (A = 338.5 mm)
- IP66 / IP67M sealing: 430 mm + stroke (A = 338.5 mm)
For a special installation length, send your required retracted and extended hole-to-hole dimensions.
Stroke and weight
- Stroke: up to 300 mm (other strokes on request)
- Aluminium: 1.35 kg @ 50 mm, 1.55 kg @ 100 mm, 1.75 kg @ 150 mm, 1.95 kg @ 200 mm, 2.15 kg @ 250 mm, 2.35 kg @ 300 mm
SLA45M Wiring, Hall Sensor & Limit Switch Options
The 230V AC version uses a 4-core bare-wire cable. Switch the supply between the red and black cores to reverse direction; built-in limit switches stop the motor at both ends of the stroke.
- White: Common line
- Red: Extend (turn around)
- Black: Retract (reverse)
- Yellow: Earth
Duty Cycle & Service Life
Duty cycle 10% (S2): run up to 2 minutes continuously, then rest 18 minutes. Rated service life ≥10,000 cycles. Operating temperature −20 °C to +85 °C; storage temperature −40 °C to +70 °C.
Download center
FAQ
What is the SLA45M?
The SLA45M is an Elerover linear actuator rated IP66.
Does Elerover manufacture the SLA45M?
Yes. Elerover is a linear actuator manufacturer and supplier. This model supports OEM configuration options listed in the product data—share your duty cycle and quantity for a factory quote.
What are the key specifications of the SLA45M?
Key ratings from the product specifications include voltage 230V AC, load 1500 N, stroke Up to 300 mm, protection IP66. See the Technical Specifications section on this page for the full table.
How do I request a quote for the SLA45M?
Send load, stroke, voltage, IP rating, duty cycle, quantity and any OEM options you need via the contact form or WhatsApp.
